Solar collectors
Separate Pressurized Solar Collector WT-C01 Series(With Heat pipe)
|
Item No. |
Solar heat Tube |
Absorber |
Daily Output |
loading Qty |
||
|
Qty/pcs |
Size/mm |
Coating |
Area(㎡) |
(50-90℃) |
20G/40G/40H |
|
|
WT-C011-15 |
15 |
Ø58×1800 |
Cu-S/S-AL-N Heat Pipe |
1.92 |
120-150L |
115/253/285 |
|
WT-C011-20 |
20 |
Ø58×1800 |
2.57 |
160-200L |
87 /193 /217 |
|
|
WT-C011-25 |
25 |
Ø58×1800 |
3.22 |
200-250L |
70 /157 /175 |
|
|
WT-C011-30 |
30 |
Ø58×1800 |
3.86 |
240-300L |
57 /126 /141 |
|
| Material | Flowing passage:High quality rose cooper（TU1) | |||||||||||
| Outer Chest:Aluminum alloy | ||||||||||||
| Bracket:Aluminum alloy |
|
|||||||||||
| Separate Pressurized Soalr Collector | ||||||||||||
| Thickness | Flowing passage:1.2mm | |||||||||||
| Heat Pipe holes:0.8mm | ||||||||||||
| Bracket:1.8mm | ||||||||||||
| Heat insulation layer:50mm | ||||||||||||
| Working Temp. | 99 Celsius degree | |||||||||||
| Working Press. | 1.0MPa(10 bars) | |||||||||||
| Coloration | Metal gray,coffee brown,rust red,shining black | |||||||||||
| Accessories | plastic bottom support,silicic gasket | |||||||||||
| Warranty | 5 years for full system/10 years for vacuum tube | |||||||||||
|
Item No. |
Solar Vacuum Tube |
Absorber |
Daily Output |
loading Qty |
||
|
qty/pcs |
size/mm |
coating |
Area(㎡) |
(50-90℃) |
20G/40G/40H |
|
|
WT-E01-20 |
20 |
Ø47×1500 |
Aluminum Nitride |
1.87 |
120L-150L |
105/220/260 |
|
WT-E01-25 |
25 |
Ø47×1500 |
2.35 |
150L-200L |
105/220/260 |
|
|
WT-E02-40 |
40 |
Ø47×1500 |
3.78 |
250L-300 |
68 / 140 /165 |
|
|
WT-E02-50 |
50 |
Ø47×1500 |
4.73 |
300L-350L |
68/140/165 |
|
| Material | Outer Chest:Galvanized steel | ||||
| Bracket:Galvanized steel | |||||
| Heat insulation layer:Polyurethane(Bayer,Germany) | |||||
| Thickness | Bracket:30×40mm | ||||
| Heat insulation layer:40mm | |||||
| Working Temp. | 99 Celsius degree | ||||
| Working Press. | 0.3MPa(3 bars) | ||||
| Coloration | shining black | ||||
| Accessories | plastic bottom support,silicic gasket | ||||
| Warranty | 5 years for full system/15 years for vacuum tube | ||||
Flat Plate Solar Collector
|
Item No. |
Solar Vacuum Tube |
Absorber |
Daily Output |
loading Qty |
|
|
qty/pcs |
size/mm |
Area(㎡) |
(50-90℃) |
20G/40G/40H |
|
|
WT-FP01-140 |
1 |
2000×1000×80 |
2 |
120-150L |
185/385/435 |
| Coating | Black chrome / Blue Titanium Coating | |||||
| Bracket:Coated galvanized steel | ||||||
| Header/riser pipe | Red copper | |||||
| Absorber | Aluminum / Red copper | |||||
| Glass Cover | Flat tempered glass (4mm) | |||||
| Working Temp. | 99 Celsius degree | |||||
| Working Press. | 1.0MPa(10 bars) | |||||
| Warranty | 5 years for full system/15 years for vacuum tube | |||||
